100W CV+CC

100W 1400mA 36-72VDC IP67 sealed LED Current Drivers Plastic housing

Model Number: APVM-100C-1400
1400mA waterproof led driver
led panel current driver
100W 1400mA 36-72VDC Current driver
Product description: 100W 1400mA 36-72VDC IP67 Waterproof LED Current Drivers Plastic housing for led strips, led modules, lightbox, cabinet lights, led panels, illuminated sky panel
INQUIRY

APVM-100C-1400 72V 1400mA 100W Single Output LED Power Supply Constant Current output

A vailable in 36W, 60W,100W,150W and 200 Watt models that act as a switching device to turn AC input voltage into a single-output current between 350 and 3500mA. This model operates at 100W/1400mA. Applications include LED-based decorative, architectural lighting, stage/theater lighting, illuminated signs, decorative lights.

Product Features
1.Constant Current mode power supply
2.180-264AC/90-132VAC Voltage input
3.Silicon-gel potting encapsulated with IP67 level for harsh conditions
4.Short circuit, over load, over voltage and over temperature protections
5.Fully isolated plastic case, CLASS 2 design, no FG
6.Cooling by free air convection -30°C to +75°C operation

Model Number: APVM-100C-1400
Constant Current LED Driver, Isolated Flicker-free
Input voltage: 200-240VAC, 47-63HZ 1.2A Max/ 90-132VAC, 2.2A Max
Output Current: 1400mA
Output voltage: 36-72VDC
Inrush Current: 60A Max at 230VAC/50Hz, full loadWorking temperature range: -40°C to 70°C
Working humidity: 10%-90%RH Non-condensing
Compliance with CE EMC LVD ROHS SELV
Dimension: 163x42x34mm,
Packing: 0.4Kg; 30pcs/13.0Kg/0.0.2CBM

Other Output Current Options:

Model NO	Input Voltage	Output Voltage	Output current	Output Power	Efficiency	Dimension/mm
APVM-100-700	200-240VAC	72-144VDC	700mA	100W	89%	162x43x32
APVM-100-1050	200-240VAC	48-96VDC	1050mA	100W	89%	162x43x32
APVM-100-1400	200-240VAC	36-72VDC	1400mA	100W	89%	162x43x32
APVM-100-1750	200-240VAC	28-57VDC	1750mA	98W	89%	162x43x32
APVM-100-2100	200-240VAC	24-48VDC	2100mA	100W	89%	162x43x32
APVM-100-2800	200-240VAC	18-36VDC	2800mA	100W	89%	162x43x32
APVM-100-3500	200-240VAC	14-27VDC	3500mA	96W	89%	162x43x32
